Camera

Effective Pixels

1920(H)*1080(V)

TV System

PAL/NTSC

Electronic Shutter

1/25s~1/50,000s , 1/30s~1/60,000s

Sync System

Internal

Usable Illumination

0.01Lux

S/N Ratio

≥50dB

Scanning System

Progressive

Video Output

Network

Lens

Focus Length

Board Len 6mm/F2.0

Focus Control

Fixed

Lens Type

Fixed

Pixels

2M Pixels

Night Vision

Infrared Distance

60M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

Ethernet

RJ-45 (10/100-T)

Protocol

IPv4, HTTP, TCP/IP, FTP, NTP, RTSP, UDP, SMTP, DNS, DDNS

ONVIF

Support ONVIF 2.4

P2P

YES, Support QR Code

POE

Optional, Support IEEE 802.3af

WIFI

N/A

Video Delay

0.3S (Within the Lan)

Main Stream

1920*1080@30fps

Sub Stream

704*576@30fps, 352*288@30fps

IE Brower

IE6-11, Google Chrome(IE Tab), Firefox(IE Tab)

Smart Phone

iPhone, iPad, Android, Android Pad

Camera Features

Day/Night

Color/ B&W (IR-CUT )

Compression

H.264/JPEG,Support record AVI format.

Image Config

Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, BLC, FLK(FlickerControl)

Motion Detection

Support

Privacy  Masking

3 Rectangular Zone

WDR

YES

Recording Mode

NVR/NAS/CMS/Web

Language

Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French,Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian

General

Housing

Vandalproof  IP66

Lens Angle Adjustment

YES, Anti-Cut 3-Axis Bracket

IR Cut Filter

YES

Operation  Temperature

-10 ~ +50  RH95% Max

Storage Temperature

-20 ~ +60  RH95% Max

Power Source

POE DC12V±10%,500mA
