Image Sensor:

1/3" Progressive Scan CMOS

Min. Illumination:

0.01Lux @(F1.2,AGC ON), 0.028Lux @(F2.0,AGC ON), 0 Lux with IR

Shutter time:

1/3 s ~ 1/100,000 s

Slow shutter:

Support

Lens:

(-I3: 4,6mm; -I5: 4,6,12mm; -I8: 6,12,16mm) @F2.0  angle of view: 83°(4mm), 55.4°(6mm),

24.7°(12mm), 19.1°(16mm)

Lens Mount:

M12

Day& Night:

IR cut filter with auto switch

Wide Dynamic Range:

120 dB

Digital noise reduction:

3D DNR

Video Compression:

H.264/MJPEG/H.264+

H.264 code profile:

Main Profile

Video bit rate:

32Kbps~16Mbps

Max. Image Resolution:

2688 × 1520

Rate:

50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720)
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720)

Image Enhancement:

BLC/3D DNR/ROI

Image Settings:

Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client s

oftware or web browser

Day/Night Switch:

Auto/Schedule/Triggered by Alarm In

Network Storage:

NAS (Support NFS,SMB/CIFS)

Alarm Trigger:

Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm,

Network disconnect ,

IP address conflict, Storage exception

Protocols:

TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE,

NTP, UPnP, SMTP,

SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour

General Function:

Anti-Flicker, heartbeat, mirror, password protection, privacy mask, watermark,

IP address filtering

System Compatibility:

ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI

Communication Interface:

1 RJ45 10M/100M/1000M Ethernet port

Operating Conditions:

-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)

Power Supply:

12 VDC ± 25%, PoE (802.3af Class3)

Power Consumption:

I3: Max. 6W; I5: Max. 7.5W; I8: Max. 10.5W

Weather Proof:

IP67

IR Range:

I3: 30 meters; I5: 50 meters; I8: 80 meters

Dimensions:

299.71 × 86.48 × 85.11(11.8’’ × 3.4’’ × 3.35’’)

Weight:

1200g (2.65 lbs)
