Camera

Image Sensor:

1/3" Progressive Scan CMOS

Min. Illumination:

0.01Lux @(F1.2,AGC ON) ,0 Lux with IR;0.07 Lux @(F2.0,AGC ON),

0 Lux with IR

Shutter time:

1/3 s ~ 1/100,000 s

Lens:

4mm Angle of view 79°

(2.8mm, 6mm,8mm,12mm optional)

Lens Mount:

M12

Day &Night

IR cut filter with auto switch

Digital Noise  Reduction

3D DNR

Wide Dynamic Range:

Digital WDR

Adjustment Range:

Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0-355°

Compression Standard

Video Compression:

H.265 /H.264 / MJPEG

H.265 code profile:

Line Profile /Main Profile

Video bit rate:

32Kbps~8Mbps

Audio Compression:

-S: G.711/G.722.1/G.726/MP2L2

Audio bit rate:

64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2)

Dual Stream

Yes


Max. Image Resolution:

2048×1536

Rate:

50Hz: 25fps (2048 × 1536,1920 × 1080,1280 × 720)

Image Settings:

Rotate mode, Saturation, Brightness,

Contrast adjustable by client software or web browser

BLC

Yes,Zone configurable

ROI

support

Network

Network Storage:

Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)

Alarm Trigger:

Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis,

Tampering alarm, Network disconnect , IP address conflict, Storage exception

Protocols:

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,

NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour

Security:

flash-prevention, dual streams, heartbeat, mirror, password protection,

privacy mask, Watermark

System Compatibility:

ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI

Interface

Communication Interface:

1 RJ45 10M/100M Ethernet interface

Alarm

S: 1 alarm I/O

Audio

-S: 1 audio I/O

Wi-Fi performance

Wireless Standard

IEEE802.11b, 802.11g, 802.11n

Frequency Range

2.4 GHz ~ 2.4835 GHz

Channel bandwidth

Support 20 / 40MHz

Safety

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

Transmission rate

11b: 11Mbps 11g: 54Mbp 11n: the upper limit of 150Mbps

Wireless Range:

50m(depend on environment)

General

Operating Conditions:

-30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing)

Power Supply:

12 VDC ± 10%, PoE (802.3af)

Power Consumption:

Max. 5W(7W with ICR on)

Impact Protection

IEC60068-275Eh, 50J; EN50102, exceeding IK10

Weather Proof:

IP66

IR Range:

Up to 30m

Dimensions:

Φ111 × 82.4 (4.4” × 3.2”)

Weight:

500g (1.1 lbs)

NOTE

"- S" denotes a one pair of audio input (Line in) / output interface (push-wire),

one pair of alarm input / output

(transistor: more than 100 mA recommendation plus relay) interfac
